Industry-specific attributes
| Brand Name | QIN/OEM |
Other attributes
| Place of Origin | Guangdong, China |
| Model Number | Cat5e/Cat6 Keystone Jack |
| Application | Network |
| Name | Cat5e/ Cat6 keystone jack faceplate |
| Connector | RJ45 |
| Certificates | ROHS |
| Suitable cable: | Cat5e/Cat6 UTP cable |
| Optional Color | White |
| Material | ABS |
| Quality standard | 100% DTX-1800 Test Passed |
| Shield Type | UTP |
Features
Features:
*Suitable for 146&86 faceplate
*Krone IDC Termination,90degree
*UK type and UTP RJ45
* Size:25*40MM
Material:
1. Housing : High Impact Flame Retardant Plastic
2. Spring Wire: Phosphor Bronze plated with 6u thick gold, over 100u thick nickle undercoat
3. IDC Plastic :Polycarbonate ( PC), UL94V Rated ( material can choose)
4. IDC Contact: Phosphor bronze plated with 100 u thick nickle, over 50u thin tin undercoat
Technical Details:
*Insertion life:750 mating cycles
*Plug Retention force:89N
*IDC Accept:22-26 AWG Solid Wire
Packing Size:35.5*31.5*51CM
