Industry-specific attributes
| Brand Name | RUBY/QIN/OEM |
Other attributes
| Place of Origin | Guangdong, China |
| Model Number | N420.660 |
| Brand | RUBY/QIN/OEM |
| Standards | ISO/IEC 11801:2002 Class E |
| Standard | ANSI/TIA/EIA/568-B.2-1 CAT.6 standard. |
| Certificate | Rohs |
| Category | UTP Cat6 |
| Plastic Parts Material | PC 94V-0 |
| Type | Toolless type |
Features
Electrical:
1. Voltage rating: 125 vac RMS
2. Current rating: 1.5 amp
3. Contact resistance: 100 milliohms max
4. Insulation resistance: 1000 megohms min @ 500 vdc
5. Dielectric strength: 750 vac RMS 60Hz, 1min
Environmental:
1. Storage: -40° To +85°
2. Operation: 0° To 70°
Mechanical:
1. Housing material: PC UL94v-0
2. Insert material: Flame retardancy ABS UL94v-0
3. PCB material: Fr-4 thickness: 1.6mm
4. Contact material: Phosphor bronze stamp pin t=0.35mm
5. Idc contact material: Phosphor bronze t=0.50mm with nickel plating
6. Wire: Awg 24-26
